MAKA MKL-R03A Infrared Thermal Imager

Description:

It is mainly used in construction automobile maintenance floor heater inspection and electrical appliances check.

Features:

• Automatic tracking
• Adjustable emissivity
• 2.8 inch display
• Fast export of USB

Specifications:

• Sensor: UFPA
• Temperature range: -10°C
• Measurement resolution: 0.1°C
• Mode: Auto
• Accuracy: ±2.0°C or ±2%
• Measuring distance: 25cm
• Response time: <500ms (95% of reading)
• Emissivity: 0.01 - 0.99 adjustable (default: 0.95)
• IR resolution: 19200 pixels (160 x 120)
• Pixel size: 17μm
• Colour palette: Iron red, rainbow, grayscale, red-white, blue-white
• Wavelength range: 8 - 14 μm
• Thermal sensitivity (NETD): <50mK
• Frame rate: <9Hz
• Image format: BMP
• General parameters
• General parameters: USB
• Product size: 236 x 75.5 x 86 mm
• Display type: 2.8 TFT LCD
• Display resolution: 320 x 240 pixels
• Battery: 3.7V / 5000mAh rechargeable
• Battery life: >/= 6 hours
• Charging time: 4 hours
• Charging voltage / current: 5V / 2A
• Image storage: Micro SD card
• Drop test: 2m
• IP rating: IP65
• Certification: CE
• Storage temperature: -20°C - 60°C
• Operating temperature: 0°C - 50°C
• Operating humidity: <90% RH (non-condensing)
• Altitude: </= 2000m

What's in the box:

• Infrared Thermal Image
• Instruction Manual

Warranty:

1 Year Local Manufacturer Warranty
